AIRPAX 67L080 Thermal Switch SPST 0.5A 48V Normally Closed 80°C TO-220 2Pin

AIRPAX 67L080 Thermal Switch SPST 0.5A 48V Normally Closed 80°C TO-220 2Pin

AIRPAX 67L080 THERMOSTAT 0.5A 48V 80°C NC(Normally Closed) TO-220

ENQUIRY!
SKU: 67L080 Categories: , Tag: Brand:

Description

AIRPAX 67L080 Thermal Switch 1A @ 120V ac, 1A @ 48V dc SPST Normally Closed 80C TO-220 Through Hole
Specification

Category Sensors, Transducers
Family Temperature Regulators (Mechanical)
Series 6700
Circuit SPST-NC
Switching Temperature 176°F (80°C)
Reset Temperature 131°F (55°C)
Current Rating – DC 0.5A (48V)
Tolerance ±9°F (±5°C)
Switching Cycles 20K
Termination Style PC Pins
Mounting Type Through Hole
Package / Case TO-220-2
Manufacturer AIRPAX
Sensor type thermostat
Output configuration NC
Opening temperature 80°C
Closing temperature 55°C
Operating current max. 1A
Max. operating voltage 120V AC
Tolerance ±6°C
Body dimensions 10.2 x 4.6 x 30mm
Features mounting hole Ø3,6mm

Product Overview

The 6700 series from Airpax are positive snap action, single pole single throw, sub-miniature bimetallic thermostat. This device provides accurate, reliable sensing and switching. The 6700 provides fast, positive response with excellent repeatability. The thermostat has a switch capability of upto 0.5A for 48VDC and achieves low level switching down to 0.001A to 0.020A at 5VDC for 100,000 cycles. It is primarily developed for thermal management applications on power supplies, the Airpax 6700 series is also ideally suited for use on crowded PC boards. Typical application include turning on indicator light, sounding an audible alarm, switch on a control circuit to send a message to a display screen or even switching a circuit to shut down a system.
  • Thermal conductivity is through terminals and the mounting bracket
  • Nickel plated copper (standard) or high pressure laminated plastic mounting bracket
  • TO-220 / Y-220 international electronic package standard
  • Ideal for surface and air sensing on PC boards and heat sinks
  • VDE approved with “P” bracket option
  • Gold plated contacts
  • Up to 20,000 life cycles at maximum standard amperage
  • Up to 100,000 life cycles at maximum gold contact amperage
  • Either close on rise (make) or open on rise (break) contact operations

Applications

Industrial; Consumer Electronics; Portable Devices; Sensing & Instrumentation; Automotive; Medical; Test & Measurement; Power Management

Manufacturer:Electronic Components
Datasheet:Others/6700.pdf

Additional information

Weight 0.001 lbs
