Description
The Alpha 153782 is a Series CVP-520 zero halogen solder paste .
The Alpha 153782 Features:
Enables elimination of a second or third reflow cycle when temperature sensitive components or connectors are used
Reduces energy consumption in reflow ovens versus standard lead free alloys
Reduces reflow process cycle time
Delivers 8 Hour stencil life
Potential eliminations of bar solder, wave soldering flux and energy costs associated with wave soldering
Compatible with all commonly used lead free surface finishes (Entek HT, Alpha Star Immersion Silver, Immersion Tin, Ni/Au, SACX HASL, etc.)
Excellent resistance to random solder balling minimizing rework and increasing first time yield
Low temperature reflow profiles may enable the use of less expensive printed circuit board substrates, when appropriate
Meets highest IPC 7095 voiding performance (Class III)
Provides excellent electrical reliability properties
Zero halogen (no halogen intentionally added) and halide-free material
Compatible with either nitrogen or air reflow
The Alpha 153782 Specifications:
Series: CVP-520
Product Type: Zero Halogen Solder Paste
Physical Form: Paste
Chemical Composition: Sn42Bi57.6Ag0.4
Applications: Soldering, Desoldering
Standards Met: IPC 7095 voiding performance Class III, IPC J-STD-005, RoHS Compliant, J-STD-004, JIS Z 3197 -1999 8.4.1, JIS Z 3197 1999, JIS Z-3284-1994 Annex 8
Container Type: Jar
Capacity: 500g
Manufacturer:Electronic Components
Datasheet:CVP520.pdf
