Description
BOURNS 4310R-102-103: Resistor Thick Film Network 10K Ohm 2% 1.25 Watt ±100PPM/C Isolated Molded 10 Pin SIP Pin Thru-Hole
Specification
Family 4300R
Type Network
Circuit Designator ISOL
Number of Resistors 5
Number of Terminals 10
Power Rating 1.25W
Power Rating per Resistor 3/10W
Resistance Value 10KOhm
Technology Thick Film
Temperature Coefficient ±100ppm/°C
Terminal Pitch 2.54mm
Termination Style Pin
Tolerance 2%
Minimum Operating Temperature -55°C
Maximum Operating Temperature 125°C
Mounting Through Hole
Case Style Molded
Package Type SIP
Package/Case SIP
Product Depth 2.16mm
Product Height 4.95mm
Product Length 24.99mm
Product Type Resistor Networks and Arrays
Manufacturer:Bourns
Datasheet:Bourns/4300R.pdf
