BOURNS 4606X-102-103 SIP Resistor Network 10Kohm 6 PIN
BOURNS 4606X-102-103 SIP Resistor Network 10Kohm 6 PIN - Image 2

BOURNS 4606X-102-103 SIP Resistor Network 10Kohm 6 PIN

Bourns – Bourns 4606X-102-103 Sip Res 6 Pin 10K Resistor

ENQUIRY!
SKU: 4606X102103 Categories: , Tags: , , Brand:

Description

4606X-102-103LF. Bourns Resistor Thick Film NET 10K Ohm 2% 3/4W ±100ppm/°C ISOL Conformal 6-Pin SIP Pin Thru-Hole Bulk

The Bourns 4600X series are thick film, resistor networks in single inline package. The number of resistor networks and configuration type are selected based on part numbering. These resistor networks helps in space sensitive applications by minimizing space, reducing costs, increasing board yields and reliability by reducing component count. Typical applications include computer, telephone equipment, telecommunication testers, satellites, optical networking and voice recognition equipment.
  • Resistance value ranges from 10 ohm to 10Mohm
  • Tolerance and power rating is based on network circuits
  • Operating voltage of 100V
  • Temperature coefficient is ±100ppm/°C and ±250ppm/°C available
  • Operating temperature ranges from -55°C to +125°C
  • Low profile is compatible with DIP package
  • Wide assortment of pin packages enhances design flexibility
  • Recommended for rosin flux and solvent clean or no clean flux processes

Applications

Industrial; Consumer Electronics; Portable Devices; Power Management

Specifications

Manufacturer: Bourns
Product Category: Resistor Networks & Arrays
RoHS: RoHS Compliant By Exemption
Brand: Bourns
Product: Networks
Termination Style: SIP
Resistor Values: 10 kOhms
Tolerance: 2 %
Circuit Type: Isolated
Number of Resistors: 3
Number of Pins: 6
Temperature Coefficient: 100 PPM / C
Operating Temperature Range: – 55 C to + 125 C
Package / Case: SIP-6
Length: 15.19 mm
Width: 2.49 mm
Height: 5.08 mm
Series: 4600X
Lead Diameter: 0.508 mm
Lead Spacing: 2.54 mm
Packaging: Bulk
Power per Element: 125 mW (1/8 W)
Power Total Package: 750 mW (3/4 W)
Qualification: Commercial
Factory Pack Quantity: 200
Type: Thick Film Conformal SIPs, Low Profile
Voltage Rating: 100 V

Manufacturer Part Number: 4606X102103
