Description
CINCH 7-140 BARRIER TERMINAL MARKER STRIP,7 POS,7-140,
CINCH,USE WITH 7-140 BLOCK STRIP 7 POS 30A 250V 10-280 AWG
Features
Interposing barriers between terminals yield higher electrical ratings and provide additional protection against frayed wire shorting.
- A wide variety of barrier blocks makes it possible to select the combination of mechanical and electrical characteristics that best meet the exact requirements of your application.
- A wide selection of optional terminals and fanning strips permits the equipment designer to choose the method of termination most suitable for his environmental specifications and manufacturing requirements.
- RoHS compliant
Materials
- Insulation Material: Molded monoblock, general purpose phenolic, black, UL Rated 94V-1
- Eyelet Material: Brass
- Eyelet Plating: Nickel
- Screw Material: Steel – 140 Std has a combination screw – with the Y terminal – binder head screw
- Screw Plating: Nickel over copper flash
- Marker Strip Material: Nema Grade XPC, UL Rated 94V-O
Environmental
- Operating Temperature: -55° to +300°F
- Certifications: UL Recognized – File E61245 CSA – LR 67357
Electrical & Mechanical Characteristics
Electrical Characteristics
- Voltage Rating: 250 VAC RMS maximum
- Current Rating: 15 Amps maximum
- Maximum Watts Per Terminal: 3750
Mechanical Characteristics
- Maximum Wire Size: #16 AWG
- Recommended Screw Eyelet Tightening Torque: 9 lb.-in.
- Recommended Screw Mounting hole Tightening Torque: 5 lbs.-in
The 7-140 is a 7-way 2-row open bottom Barrier Terminal Block with standard screw and 16AWG maximum wire size. This 140 series terminal block has black general purpose phenolic molded monoblock insulation, nickel-plated brass eyelet, nickel over copper flash steel screw, electro-tin-plated brass solder terminal and NEMA grade XPC marker strip. Interposing barriers between terminals yield higher electrical ratings and provide additional protection against frayed wire shorting.
- UL94V-1 and UL94V-0 Flammability rating
- -55 to +300°F Operating temperature range
Applications
Commercial
Manufacturer Part Number: 7-140
Cinch
