Description
CMC-4015-25T CUI Microphone 4.0 mm, Omnidirectional, Terminal Mount, Electret Condenser 3VDC -25DB Terminal 6mm
Specifications
Directivity Omnidirectional
Sensitivity (db) -25
Operating Voltage (Vdc) 3
Sensitivity Reduction (dB) -3
Operating Freq. (Hz) 100 ~ 20000
Signal : Noise Ratio (dBA) 62
Output Impedance (KO) 2.2
Termination Terminal Type
Diameter (mm) 4
Diameter (in) 0.16
Depth (mm) 1.5
Depth (in) 0.06
Manufacturer:CUI
Datasheet:cmc-4015-25t.pdf
