Description
CRANE PEG10DS-TIQ640 HEADER CONNECTOR,PCB MNT,RECEPT,10 CONTACTS,PIN,0.1 PITCH, RoHS
Features
MATE-RITE TIP prevents scraping of mating socket
Insulator standoffs reduce rework due to flux residue
Board retention option prevents unwanted movement
Coined tails improve solder action
Mates with Crane’s ATP, ATS, ABH, ABS, ABT Sockets; JUN jumpers
0.100″ (2,54mm) Centers To Mate With 0.025″ (0,64mm) Square Mating Posts
SPECIFICATIONS
Part #: PEG10DS-GBR
Part Category: Connectors
Manufacturer: Crane Connectors
Description: 10 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER
Connector Type BOARD CONNECTOR
Body Breadth 0.1980 inch
Body Depth 0.0980 inch
Body Diameter 0.5000 inch
Body/Shell Style RECEPTACLE
Contact Finish – Mating GOLD (15) OVER NICKEL (50)
Contact Finish – Termination Tin/Lead (Sn/Pb) – with Nickel (Ni) barrier
Contact Gender MALE
Contact Material PHOSPHOR BRONZE
Manufacturer:Electronic Components
Datasheet:CRANS00036-1.pdf
