Description
The F2211/16 BK001 from Alpha Wire is a black Heat Shrink Tubing made of cross-linked polyolefin. The tubing offers 2:1 shrink ratio and 1500psi minimum tensile strength.
Specifications
Manufacturer: Alpha Wire
Product Category: Heat Shrink Tubing and Sleeves
RoHS
Color: Black
Material: Polyolefin (PO)
Inside Diameter: 0.063 in
Recovered Diameter: 0.031 in
Shrink Ratio: 2:1
Series: FIT-221
Chemical Resistant: Yes
Family: General Purpose Heat Shrink Products
Features: XTRA-GUARD 1 applications
Minimum Shrink Temperature: + 90 C
Product: Heat Shrink Tubing
Brand: Alpha Wire
Flammability Rating: UL 224
Maximum Temperature: + 135 C
Dielectric Strength: 500 V/mil
Maximum Operating Temperature: + 135 C
Minimum Operating Temperature: – 55 C
Product Type: Heat Shrink Tubing and Sleeves
Factory Pack Quantity: 1
Subcategory: Wire & Cable Management
Part # Aliases: BK001 F2211/16
Unit Weight: 3 lbs
Our FIT-221-3/4 heat shrink tubing is part of our Alpha Wire, Cable, & Tubing line. It has an expanded outer diameter of 3/4 and a 2:1 shrink ratio at 121°C. Alpha FIT-221 is made of irradiated polyolefin (PO) material with an operational temperature range of -55°C to 135°C, a max tensile strength of 1500 psi and a dielectric strength of 800 V/mil. This heat shrink tubing is designed to reduce production time and protect heat sensitive components in automatic assembly and cable jacketing applications. FIT-221-3/4 possesses excellent physical, chemical, and electrical properties. When heated, the tubing forms a tight mechanical bond, providing insulation and protection.
Manufacturer Part Number: FIT-221-1/16-BK001
Manufacturer: Electronic Components
