Fairchild 6N137 High Speed Optocoupler 10 Mbit/s DIP-8

Fairchild 6N137 High Speed Optocoupler 10 Mbit/s DIP-8

6N137 Fairchild Single-Channel High Speed Logic Gate Output Optocoupler 1.4 V to 5V 10mA 8-Pin DIP 10 Mbit/s

ENQUIRY!
SKU: 6N137. Categories: , , Tag: Brand:

Description

FAIRCHILD 6N137 High Speed Optocoupler Logic-Out Open Collector 10 Mbit/s DIP-8 Through Hole

The 6N137, HCPL2601, HCPL2611 single-channel and HCPL2630, HCPL2631 dual-channel optocouplers consist of a 850 nm AlGaAS LED, optically coupled to a very high speed integrated photo-detector logic gate with a strobable output. This output features an open collector, thereby permitting wired OR outputs. The coupled parameters are guaranteed over the temperature range of -40°C to +85°C. A maximum input signal of 5mA will provide a minimum output sink current of 13mA (fan out of 8).

An internal noise shield provides superior common mode rejection of typically 10kV/µs. The HCPL2601 and HCPL2631 has a minimum CMR of 5kV/µs. The HCPL2611 has a minimum CMR of 10kV/µs.

Features

  • Very high speed – 10 MBit/s
  • Superior CMR – 10 kV/µs
  • Double working voltage-480V
  • Fan-out of 8 over -40°C to +85°C
  • Logic gate output
  • Strobable output
  • Wired OR-open collector
  • U.L. recognized (File # E90700)
The 6N137 is a High Speed Optocoupler with a GaAIAs infrared emitting diode, optically coupled with an integrated photo detector which consists of a photo diode and a high-speed transistor. Signals can be transmitted between two electrically separated circuits up to frequencies of 2MHz. The potential difference between the circuits to be coupled should not exceed the maximum permissible reference voltages.
  • TTL compatible
  • 1Mbps High speed
  • High common-mode interference immunity
  • Open-collector output
  • External base wiring possible

Applications

Industrial; Communications & Networking

Specifications

Manufacturer: Fairchild Semiconductor
Product Category: High Speed Optocouplers
RoHS: RoHS Compliant
Package / Case: DIP-8
Data Rate: 10 Mbps
Number of Channels: 1 Channel
Output Type: Open Collector
Isolation Voltage: 2500 Vrms
Vf – Forward Voltage: 1.4 V
If – Forward Current: 10 mA
Vr – Reverse Voltage: 5 V
Pd – Power Dissipation: 100 mW
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: – 40 C
Series: 6N137
Packaging: Bulk
Brand: Fairchild Semiconductor
Fall Time: 12 ns
Maximum Collector Current: 50 mA
Output Current: 50 mA
Rise Time: 50 ns
Factory Pack Quantity: 1000
Part # Aliases: 6N137_NL
Unit Weight: 0.028889 oz
Manufacturer:Electronic Components
Datasheet:Fairchild/94980.pdf

Additional information

Weight 0.001 lbs
