FELLER, LLC World Wide Jumper Cord Sets

Description

World Wide Jumper Cord Sets

Meets requirements of North American and International Safety Agencies
Plug Standard: IEC320/EN60320-2.2/E, Feller type C14G, C16G
Cord Connector: IEC320/EN60320/C13, C15 Feller type C13, C15

Jumper Cords are used to power accessories. Both ends, the shrouded male and the female are per the IEC 320 standard for worldwide use.

Feller can build a variety of fully molded jumper cords with ratings from 2.5A up to 20A for Class I and Class II equipment, including cords for “hot” conditions.

A Feller specialty is the “universal cordage” that is used to build jumper cords. It is harmonized, UL listed, CSA certified and approved in Australia. The respective markings and type designations are embossed on the outer jacket. The Feller type designations are HARSVT and HARSJT.

“Universal” cords eliminate the need to have separate cords for North American and International markets, enabling OEM`s to reduce inventory.

Plugs, connectors and universal cordage bear the CE-mark


Universal Jumper Cords For Class I Equipment 2.5A-20A / 250V
	Part Number	Current/ Voltage Rating	Cordage	Connector Style	Length	Color
	3517-840-0-3001	2.5A/125V	HARSVT3x0.75mm²	straight/C5	3’3″(1.0m)	black

	3522-00	10A/250V	HARSVT3x18AWG	straight/ C13	3’3″(1.0m)	black
	3522-01				6’7″(2m)
	3522-02				8’2″(2.5m)
	3522-03				10′(3m)

	3522-04	10A/250V	HARSJT3x18AWG	straight/ C13	3’3″(1.0m)	black
	3530-620-0-6001				6’7″(2m)
	3522-05				8’2″(2.5m)
	3530-620-0-1001				10′(3m)

	Part Number	Current/ Voltage Rating	Cordage	Connector Style	Length	Color
	3530-640-0-6001	15A/250V	HARSJT3x14AWG	straight/ C13	9’2″(2.8m)	black

	C14 3537-341-0-4001	13A/250V	SJT3X16AWG	straight/ C15	2’5″(0.76m)	black

	C16 4637-230	10A/250V	H05VVF3G1.00mm²	straight/ C15	8’2″(2.5m)	black
	Part Number	Current/ Voltage Rating	Cordage	Connector Style	Length	Color
	C16 4637-340	13A/250V	SJT3X16AWG	straight/ C15	8’2″(2.5m)	black

If you need the real power! Both ends fully molded – noassemblies necessary ! Plug Standard: IEC320/EN60320-2.2I, Feller type C20 Cord Connector: IEC320/EN60320/C19, Feller type C19
	Part Number	Current/ Voltage Rating	Cordage	Connector Style	Length	Color
	4041-240 International use only	16A/250V	H05VVF3G1.5mm²	straight/ C19	8’2″(2.5m)	black

	4041-640	16A/250V	universal type HARSJT3x14AWG	straight/ C19	10′(3m)	black
	4041-640-0-0001				8’2″(2.5m)
	4041-640-0-5001				13’2″(4m)
	4041-640-0-4001				2’2″(0.65m)

	4041-360 N.A. use only	20A/250V	SJT3X12AWG	straight/ C19	8’2″(2.5m)	bla
