Description
HEAL LC2*0R010J HTR LOW OHM/LOW INDUCTANCE RESISTOR, HEAL SERIES, 2.5W, 0.01OHM, 5% RoHS
Description RES, AXIAL, METAL ALLOY, 0.01ohm, 5% +/-TOL, 5924 CASE
Package Description Axial, 5924
Manufacturer Hi-Tech Resistors Pvt Ltd
Construction All-Welded
Lead Diameter 800 µm
Lead Length 35 mm
Manufacturer Series HEAL(LC2,5%TOL)
Operating Temperature-Max 155 °C
Operating Temperature-Min -40 °C
Package Height 6 mm
Package Length 15 mm
Package Style Axial
Package Width 6 mm
Packing Method Tape
Rated Power Dissipation (P) 2.5 W
Resistance 14 mO
Resistor Type FIXED RESISTOR
Series HEAL(LC2,5%TOL)
Size Code 5924
Subcategory Fixed Resistors
Technology METAL ALLOY
Tolerance 5 %
Manufacturer:HTR Resistors
Datasheet:HTR/Hitech-HEAL.pdf
