Description
HITACHI HM6264ALFP-12 91 D/C IC 8192-word x 8-bit High Speed CMOS Static RAM SOP-28
The Hitachi is 64k-bit static RAM organized 8-bit. It realizes higher performance and low power consumption 1.5 µm CMOS process technology. The device, packaged in 450 mil SOP (foot print pitch width), 600 mil plastic DIP, 300 mil plastic DIP, is available for high density mounting.
Features
High speed Fast access time: 85/100 ns (max) Low power Standby: 10 µW (typ) Operation: 15 mW (typ) = 1 MHz) Single 5 V supply Completely static memory No clock or timing strobe required Equal access and cycle times Common data input and output Three state output Directly TTL compatible All inputs and outputs Battery backup operation capability
Manufacturer:Renesas
Datasheet:HM6264ALFP-12T.pdf
