Description
The HPV power supply series realizes very high power efficiency in a space-saving housing. This design enables Green Power applications and allows free air convection. Latest generation electrical devices relate to the high reliability of all Camtec products. The Camtec philosophy is, to employ 125°C low ESR ultra long life capacitors where expedient to achieve a superior lifetime of our products. The used screw terminals allow easy to wire and smooth service.
Parallel Operation Mode:
Parallel operation of equal HPV-Power-Supplies provides you
a higher output power. Make sure that the DC voltages differ
at only ±1% and that DC cables are equal of equal length.
Series Operation Mode:
To raise the output voltage you can drive equal HPV Power
Supplies in series, too.
| Model | HPV10001 | |||
| Power | 1008W | |||
| Nominal AC Input | 115/230Vac | |||
| Input Range AC | 90..115Vac/186..265Vac | |||
| Input Range DC | 250… 375Vdc | |||
| Input Frequency | 47… 63Hz | |||
| Hold-Up Time | 30ms | |||
| Inrush Current Protection | NTC < 84A | |||
| Autostart | Soft start 100ms | |||
| Output Voltage | 72V | 110V | 150V | 240V |
| Adjust Range Vout | 58… 86V | 86… 132V | 132… 180V | 180… 240V |
| Ripple & Noise mVpp | 200mV | 250mV | 250mV | 300mV |
| Nominal Output Current | 13,9A | 9,1A | 6,7A | 4,6A |
| Power Boost <=60°C/60s | 15,3A | 10A | 7,4A | 5A |
| Stability at Load Switch | ±0,5% | |||
| Transient Time | < 1ms | |||
| Efficiency | 0,93 | |||
| Basic load | Idling-proof | |||
| Short Circuit Protection | Continuous | |||
| Ambient Operation Temperature | -20°C… +70°C | |||
| Cooling | Natural convection + controlled fan from Papst | |||
| Temperature Monitoring | Yes | |||
| Dimensions (WxHxD) | 200x156x114,5mm | |||
| IP-Range | IP20 | |||
| Safety Norms | CSA UL CE according to IEC60950-1 | |||
| Safety IEC | EN60950-1 EN50178 EN60204-1 | |||
| Safety Class 1(A) | VDE0100 VDE0805 | |||
| Input to Output Isolation | 3000Vac | |||
| Climatic Class, Humidity | 3k3, 95% non condensing | |||
| EMI | EN55022B | |||
| EMS | EN61000-6-2,3 | |||
| MTBF IEC61709 | 500000h | |||
| Power Good Relay | Yes, Option | |||
| Ordering options | Protective coating, Popwer Good Relais (PG) | |||
| Options | See datasheet | |||
Manufacturer:Camtec
Datasheet:technical-data-sheet-camtec-hpv10001.72t-en-20160311.pdf
