Description
HSW00901.024 Camtec Power Supplies 24V 90W DIN-Rail 1phase Fixed Output TS35mm RoHS V/I characteristic, with convection cooling, sustained short circuit-proof, open circuit-proof; Extended range input: 85 to 265 VAC, 110 to 375 VDC. MTBF: 500000 h. Operating temperatures: 20 to +70C. Backup time (230 VAC): 40 ms.
The HSW power supply series realizes very high power efficiency in a small housing. Latest generation electrical devices relate to the high reliability of all Camtec products. The Camtec philosophy is, to employ 125C low ESR ultra long life capacitors where expedient to achieve a superior lifetime. The used screwing terminals allow easy to wire, smooth service and protection from mixing-up the input with the output connections.
Parallel Operation Mode: Parallel operation of equal HSW-Power-Supplies provides you a higher output power. Make sure that the DC voltages differ is only 1% and that DC cables are equal of equal length.
Series Operation Mode: To raise the output voltage you can drive equal HSW power supplies in series, too.
Sensing: Only for 5V-version available. Compensation: 200mV
Number of outputs:1
Length:96 mm
Height:102 mm
efficiency:90 %
Output current:3.2 A
Width:50 mm
Input voltage AC:85-265 VAC
Output voltage DC:24 VDC
Power:75 W
Manufacturer:CAMTEC
Series:HSW00751
Manufacturer number:HSW00751.24T
Country of origin:Germany
Customs tariff number:85043121
Dimensions: 50 x 102 x 96 mm. Weight: 300g.
Manufacturer:Camtec
Datasheet:Camtec/camtec-hsw00751.pdf
