Description
ISPLSI 1032E-100LJN Lattice Complex Programmable Logic Devices CPLD ispLSI 1000E Family 6K Gates 128 Macro Cells 100MHz 5V 84-Pin PLCC RoHS
Specifications
Manufacturer:Lattice
Product Category:CPLD – Complex Programmable Logic Devices
RoHS
Product:ispLSI 1032E
Number of Macrocells:128
Number of Logic Array Blocks – LABs:32
Maximum Operating Frequency:125 MHz
Propagation Delay – Max:12.5 ns
Number of I/Os:64 I/O
Operating Supply Voltage:5 V
Minimum Operating Temperature:0 C
Maximum Operating Temperature:+ 70 C
Mounting Style:SMD/SMT
Package/Case:PLCC-84
Packaging:Tube
Height:3.68 mm
Length:29.31 mm
Memory Type:EEPROM
Series:ispLSI 1032E
Width:29.31 mm
Brand:Lattice
Number of Gates:6000
Moisture Sensitive:Yes
Operating Supply Current:190 mA
Product Type:CPLD – Complex Programmable Logic Devices
Factory Pack Quantity:15
Subcategory:Programmable Logic ICs
Supply Voltage – Max:5.25 V
Supply Voltage – Min:4.75 V
Tradename:ispLSI
Unit Weight:6.778 g
Obsolete
Manufacturer:Lattice
Datasheet:ISPLSI.pdf
