Description
Kingstate KPE-242 PIEZO BUZZER 3200Hz – 4.1KHZ, 70DB
The KPE242 from Kingstate is a pin type piezo indicator.
- Rated frequency of 4.2KHz
- Operating voltage range from 3VDC to 16VDC
- Maximum current consumption of 7mA at 12VDC
- Minimum sound pressure level of 70dB at 30cm/12VDC
- Continuous tone
- Operating temperature range from -20°C to 70°C
- Material noryl is black
- Dimension of 13.7mm x 7.6mm
- Internal circuitry type
Applications
Audio; Consumer Electronics; Portable Devices
- Rated Frequency: 4,100Hz
- Operating Voltage: 3 – 16Vdc (DC input)
- Current Consumption: 7mA @ 12Vdc
- Sound Pressure Level(30cm): 70dB @ 12Vdc
- Kingstate Buzzer – KPEG242
- Dimensions: 13mm Diameter, 7mm High, Pin Spacing – 7mm
established in 1977, Taiwan’s first professional electro-acoustic company, Kingstate R&D and production of buzzer, micro-receiver, condenser microphone, headphones, Bluetooth speakers, hearing aids and other complete sound products. Kingstate has thirty-nine years has always been to provide customers with high quality and all-round electro-acoustic solutions.
Manufacturer:Electronic Components
Datasheet:DSARS0025242.pdf
