Description
LCA1-56H-E Panduit One-hole standard barrel mechanical lug with window and 45 angled tongue – for #1AWG conductors – 5/16″ stud hole – Panduit (Pan-Lug LCA series) – UPC code 7498355831 – equivalent to LCA156HE RoHS
Panduit Pan-Lug Compression Connectors provide permanent terminations for a variety of power and grounding applications, with innovation, highest reliability, and lowest installed cost. Panduit offers the first and only copper compression lugs and splices that meet Network Equipment-Building Systems (NEBS) Level 3 requirements as tested by Telcordia Technologies. NEBS Level 3 assures that product performance is suitable for equipment applications that demand minimal service interruptions over the life span of the equipment.
Product Attributes
Category Connectors, Interconnects
Terminals – Rectangular Connectors
Mfr Panduit Corp
Series Pan-Lug
Package Bulk
Terminal Type Rectangular Tongue
Stud/Tab Size 5/16 Stud
Terminal Style Single Stud Hole
Tab Thickness 0.110″” (2.79mm)
Width – Outer Edges 0.700″” (17.78mm)
Mounting Type Free Hanging (In-Line), 45 Angle
Termination Crimp, Barrel
Wire Gauge 1 AWG
Insulation Non-Insulated
Color Green
Contact Finish Electro-Tin
Contact Material Copper
Diameter – Barrel ID 0.360″” (9.14mm)
Diameter – Barrel OD 0.470″” (11.94mm)
Diameter – Ring ID 0.340″” (8.64mm)
Manufacturer: Panduit
MFG Part #: LCA1-56H-E
