Description
Panduit Corp LCD2/0-38D-X Two-hole, standard barrel lug with window, 2/0 AWG wire, 3/8″ stud hole, 1″ hole spacing.
Copper Compression Lug, Lug Terminal (2/0)AWG 79.8mm 21.6mm Tin
Conductor Material Copper
Product Type Tin-Plated Copper Compression Connectors – Lugs
Angle Straight
Barrel Type Standard Barrel Length with Inspection Window
Corona Relief Taper No
Tongue Type Standard
Code Conductor Size 2/0 AWG Code
Stud Hole Size In. (mm) 3/8 (9.5)
Stud Hole Spacing In. (mm) 1 (25.4)
Barrel Length In. (mm) 0.98 (24.9)
Length In (mm) 3.14 (79.8)
Tongue Thickness In. (mm) 0.13 (3.3)
Tongue Width In. (mm) 0.85 (21.6)
Panduit Color Code Black
Panduit Die Index No. P45
Wire Strip Length In. (mm) 1.0625 (27)
Burndy Die Index No. 13
T&B Die Index No. 45
American Bureau Shipping Approved Yes
CSA Certified C22.2 No. 65-13
Tested by Telcordia-Meets NEBS Level 3 Yes
Tin-Plating Meets ASTM B545-97, Class C 320µ in (8µ m)
UL Listed 486A-486B
UL and CSA Temperature Rating 90°
UL and CSA Voltage Rating 35kV
Part Number Series LCD
Part Features Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
RoHS Compliancy Status Compliant
Min. Order Qty. 1.0000
Manufacturer Part Number: LCD2/0-38D-X
Manufacturer: Panduit
