Description
Ledtronics L120TR6N LED Uni-Color Red 656nm 2-Pin T-1
SPECIFICATIONS
Part #: L120TR6N
Part Category: Optoelectronics
Manufacturer: LEDtronics, Inc.
Mfr Package Description 2 PIN
EU RoHS Compliant Yes
Optoelectronic Device Type SINGLE COLOR LED
Color ULTRA RED
Configuration SINGLE
Forward Current-Max 0.03 A
Lens Type DIFFUSED
Luminous Intensity-Nom (mcd) 180.0
Mounting Feature RADIAL MOUNT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description 2 PIN
Manufacturer LEDtronics Inc
Risk Rank 5.71
Distributor Sierra IC,Master Electronics
Color ULTRA RED
Configuration SINGLE
Forward Current-Max 30 mA
Lens Type DIFFUSED
Luminous Intensity-Nom 180.0 mcd
Mounting Feature RADIAL MOUNT
Number of Functions 1
Number of Terminals 2
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Optoelectronic Device Type SINGLE COLOR LED
Overall Height 4.5 mm
Packing Method BULK
Peak Wavelength 660 nm
Shape ROUND
Size 3 mm
Surface Mount NO
T-code T-1
Terminal Pitch 2.54 mm
Viewing Angle 50 deg
Manufacturer Part Number: L120TR6N
Manufacturer: Ledtronics
