Description
Ledtronics SML12RG4H-TR LED Bi-Color Green/Red 565nm/644nm 4-Pin Chip T/R
SPECS
Supplier: Ledtronics
Part No: SML12RG4H-TR
RoHS: Unknown
HTS: 8541402000
COO: US
ECCN: EAR99
Standard Pack: 3,000
Category: Chip LED
Color: Green/Red
Color Temperature: N/A
Dimension: 2.7 x 3.2 mm
Dominant Wavelength: 571/628 nm
Family: SML12RG4H
High Brightness: No
Intensity: 14,8 mcd
Lens Appearance: Colorless Non Diffused
Lens Dimensions: 2×3.2×0.6 mm
Lens Shape Type: Rectangular
Maximum Forward Current: 30 mA
Maximum Forward Voltage per Color: 2.6 V
Maximum Power Dissipation: 80 mW
Mounting: Surface Mount
Mounting Orientation: Top Mount
Number of LEDs: 2
Operating Temperature: -25 to 80 °C
Packaging: Tape and Reel
Peak Wavelength: 565/644 nm
Pin Count: 4
Reverse Voltage: 5 V
Supplier Package: Chip
Type: Bi-Color
Viewing Angle: 120 °
Manufacturer Part Number: SML12RG4H-TR
Manufacturer: Ledtronics
