Description
Loctite 348 surface mount adhesive (Chipbonder) is designed for the bonding of surface mounted devices to printed circuit boards prior to wave soldering. Particularly suited for applications where medium- to high-dispense speeds, high-dot profile, high-wet strength and good electrical characteristics are required.
348 is a very fast curing, one-component epoxy resin, shear thinning adhesive. One-component requires no mixing and is heat cure. Medium dispense speed of 15000 – 25000 dots/hr. High dot profile reaches components with large standoffs.
SPECS
Performance Details
Full Cure Time 90 sec at 150 deg C
Shear Strength 1450 psi at 150 deg C
Design & Construction
Form Paste
Color Orange
Cure Type Heat Cure
Electrical Properties
Dielectric Strength See TDS
Supporting Information
Application Method Medium Speed Syringe Dispensing
Chemical Properties
Composition Epoxy
Specific Gravity 1.2
Physical Properties
Container Size 10mL
Container Type Syringe
Manufacturer: Loctite
MFG Part #: 348-10ML
