Description
LOCTITE 223102 (CB8008-V98) 3609 CHIPBONDER, 30ML SYRINGE
3609™ is designed for the bonding of surface mounted devices to printed circuit boards prior to wave soldering. Particularly suited for applications where medium to high dispense speeds, high dot profile, high wet strength and good electrical characteristics are required. 3609™ has been used successfully in lead free processes with water and alcohol based fluxes under conditions outlined in the Environmental Resistance section.
The Loctite 223102 is a red/orange liquid epoxy adhesive in a 30 ml syringe. It is designed for the bonding of surface mounted devices to printed circuit boards prior to wave soldering.
Loctite 223102 Specifications:
Series: 3609
Product Type: Epoxy Adhesive
Color: Red/Orange
Primary Color: Red/Orange
Physical Form: Liquid
Cure Time: 90 to 120s
Viscosity Measurement: 0.16 to 2Pa/s
Shelf Life: 6month
Chemical Composition: Epoxy Resin, Polyamide Hardener, Epoxy Resin, Treated Fumed Silica, Diethylenetriamine
Specific Gravity: 1.1
VOCs Content: 2.46g/L
Odor: Mild Petroleum
Cure Type: Heat Cure
Container Capacity: 30ml
Container Type: Syringe
Applications: Surface Mount Adhesive
Manufacturer Part Number: 3609-30ML
Loctite
