Description
M22-2520846 Harwin Connector M22 (2mm Pitch) DIL Vertical Pin Header Throughboard Connector – M22-2520846
2.00mm (0.079″) Pitch PCB Connector (PCB Header/Pin Header)
Double Row, 2.3mm PC Tail, 3.5mm mating pin height – 16 contacts (8+8).
Tin finish on contact area and termination.
Specifications
Manufacturer: Harwin
Product Category: Headers & Wire Housings
RoHS
Product: Headers
Type: Pin Strip
Number of Positions: 8 Position
Pitch: 2 mm
Number of Rows: 2 Row
Mounting Style: Through Hole
Termination Style: Through Hole
Mounting Angle: Vertical
Contact Plating: Tin
Series: M22
Current Rating: 1 A
Housing Material: Nylon
Voltage Rating: 650 V
Brand: Harwin
Contact Material: Phosphor Bronze
Factory Pack Quantity: 500
Unit Weight: 0.012699 oz
Manufacturer Part Number: M22-2520846
Manufacturer: Harwin
