Description
M80-5101042 Harwin Connector Header Through Hole 10 position 0.079 Headers & Wire Housings 5+5 POS VERT MALE 3mm TAIL W/JS TIN
Specifications
Manufacturer: Harwin
Product Category: Headers & Wire Housings
RoHS
Product: Headers
Type: Shrouded
Number of Positions: 10 Position
Pitch: 2 mm
Number of Rows: 2 Row
Mounting Style: Mounting Flange
Termination Style: Through Hole
Mounting Angle: Straight
Contact Gender: Pin (Male)
Contact Plating: Gold
Termination Post Length: 3.3 mm
Series: J-Tek
Tradename: DATAMATE
Current Rating: 3 A
Housing Material: Polyphenylene Sulfide (PPS)
Brand: Harwin
Contact Material: Phosphor Bronze
Flammability Rating: UL 94 V-0
Row Spacing: 2 mm
Insulation Resistance: 100 MOhms
Latching Type: Jackscrew
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: – 55 C
Factory Pack Quantity: 13
Part # Aliases: M80-5T11042M2-00-000-00-000
Unit Weight: 0.035274 oz
Manufacturer Part Number: M80-5101042
Manufacturer: Harwin
