Description
MAX9022AKA+T Maxim Integrated Analog Comparators Micropower, Ultra-Small, Single/Dual/Quad Single-Supply Comparator 2.75V/5.5V 8PIN SOT-23 T/R RoHS
Specifications
Manufacturer: Maxim Integrated
Product Category: Analog Comparators
Mounting Style: SMD/SMT
Package / Case: SOT-23-8
Number of Channels: 2 Channel
Comparator Type: General Purpose
Supply Voltage – Min: 2.5 V
Supply Voltage – Max: 5.5 V
Operating Supply Current: 5.6 uA
Vos – Input Offset Voltage: 1 mV
Ib – Input Bias Current: 3 nA
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 125 C
Series: MAX9022
Packaging: Cut Tape
Packaging: Reel
Height: 1.1 mm
Length: 2.9 mm
Product: Analog Comparators
Supply Type: Single, Dual
Type: Micro Power Comparator
Width: 1.63 mm
Brand: Maxim Integrated
Shutdown: No Shutdown
CMRR – Common Mode Rejection Ratio: 100 dB
GBP – Gain Bandwidth Product: –
Maximum Dual Supply Voltage: +/- 2.75 V
Minimum Dual Supply Voltage: +/- 1.25 V
Operating Supply Voltage: 3 V, 5 V
Pd – Power Dissipation: 727 mW
Product Type: Analog Comparators
PSRR – Power Supply Rejection Ratio: 80 dB
Factory Pack Quantity: 2500
Subcategory: Amplifier ICs
Part # Aliases: MAX9022
Unit Weight: 0.001411 oz
The MAX9022AKA+T is a micropower, ultra small, dual comparator in 8 pin SOT-23 package. This comparator is optimized for low power consumption while still providing fast output response. It is designed for single supply applications from 2.5V to 5.5V and can also operate from dual supplies. It has 3?s propagation delay and consumes 2.8?A of low supply current. The combination of low power, single supply operation down to 2.5V and ultra small footprint makes this device ideal for many applications. The MAX9022 has 4mV of built-in hysteresis to provide noise immunity and prevent oscillations even with slow moving input signal. The design of comparator output stage substantially reduces switching current during output transitions by eliminating power supply glitches. It is used in sensor signal detection, photodiode preamps, digital line receivers, keyless entry systems & threshold detectors/discriminators.
Manufacturer Part Number: MAX9022AKA+T
Manufacturer: Maxim
