Description
Maxim DG508ACJ+ Multiplexer Switch 1 Circuit 8 x 1 15V 0.842W PDIP-16 RoHS
Product Attributes Select All
Categories Integrated Circuits (ICs)
Interface – Analog Switches, Multiplexers, Demultiplexers
Manufacturer Maxim Integrated
Multiplexer/Demultiplexer Circuit 8:1
Number of Circuits 1
On-State Resistance (Max) 450 Ohm
Channel-to-Channel Matching (?Ron) 27 Ohm
Voltage – Supply, Dual (V±) ±4.5 V ~ 18 V
Switch Time (Ton, Toff) (Max) 1.5µs, 1µs
Channel Capacitance (CS(off), CD(off)) 5pF, 25pF
Current – Leakage (IS(off)) (Max) 1nA
Operating Temperature 0°C ~ 70°C (TA)
Package / Case 16-DIP (0.300″, 7.62mm)
Supplier Device Package 16-PDIP
Manufacturer:Maxim
Datasheet:Maxim/DG508A-DG509A.pdf
