MLSS100-3-D ITW

MLSS100-3-D ITW Wire-To-Board Connector, 2.54 mm, 3 Contacts, Header, 1 Rows

MLSS100-3-D ITW / Pancon Corporation Connector Unshrouded Header HDR 3 POS 2.54mm Solder ST Thru-Hole

ENQUIRY!
SKU: MLSS100-3-D Categories: , Tags: , Brand:

Description

MLSS100-3-D Pin Header; W ire-to-Board; No. of Con tacts:3; Pitch Spacing:0. 1; Through Hole; Contact Material:Copper Alloy; S eries:MLSS; Plating:Tin; 1 Row ;RoHS Manufacturer: ITW

The MLSS100-3-D is a 3-way 1-row MAS-CON® Male 0.100-inch Locking Header with straight pins, tin over nickel plated copper contacts and thermoplastic housing. The MAS-CON® wire-to-board connector has 0.140-inch PC tail and through hole termination.
  • UL94V-0 Flammability rating
  • 5000MΩ Insulation resistance
  • 300V Voltage rating
  • 4A Current rating per contact

Part Number: MLSS100-3-D
Agency Cert cULus
Product Family Pancon Connectors
Product Name MAS-CON® .100″ IDC Wire to Board Connector System
Brand Name Locking Headers – Straight
Rohs Status COMPLIANT
Comp Type Header
Term Method Solder
Contact Material Copper Alloy
Contact Plating Bright Tin over Nickel
Housing Material Thermoplastic
Dielectric Voltage 2.0 KVAC Min.
Flammability UL 94 V-0
Insulation Resistance 5,000 Megohms Min
Packaging Type Bag
Standard Pack Size 500
Product Specification PS 1005
Sales Drawing KA-10148.pdf
Stackable YES
Polarized To Mating Part YES
Lock To Mating Part YES
Polarization YES
Breakaway NO
Current Max Per Contact 4.0 amps
Voltage Max 300 volts
Num Rows 1
Pitch Mating .100″
Pc Tail Length .140″
Spacing .100″
Gender Male
Manufacturer Part Number: MLSS100-3-D
Manufacturer: ITW
