Description
44432-0802 MOLEX Micro-Fit BMI™ Header, Surface Mount Compatible, Dual Row, Vertical, with PCB Polarizing Peg, 8 Circuits, Tin (Sn) Plating
Part Detail
Category PCB Headers
Series 44432
Application Board-to-Board, Power, Wire-to-Board
Comments High Temperature, Square Pin, Offset Through Hole Mounting, Solder Type
Overview Micro-Fit 3.0™ Connectors
Product Literature Order No 987650-5984
Product Name Micro-Fit BMI™
UPC 800756378107
Physical
Breakaway No
Circuits (Loaded) 8
Circuits (maximum) 8
Color – Resin Black
Durability (mating cycles max) 30
Flammability 94V-0
Glow-Wire Compliant No
Material – Metal Brass
Material – Plating Mating Gold
Material – Plating Termination Tin
Material – Resin High Temperature Thermoplastic
Net Weight 1.766/g
Number of Rows 2
Orientation Vertical
PC Tail Length 3.30mm
PCB Locator Yes
PCB Retention Yes
PCB Thickness – Recommended 1.60mm
Packaging Type Tray
Pitch – Mating Interface 3.00mm
Plating min – Mating 0.381µm
Plating min – Termination 2.540µm
Polarized to PCB Yes
Shrouded Fully
Stackable No
Surface Mount Compatible (SMC) Yes
Temperature Range – Operating -40°C to +105°C
Termination Interface: Style Through Hole
Electrical
(Please review the Product Specification for specific details.)
Current – Maximum per Contact 5.0A
Voltage – Maximum 250V AC (RMS)/DC
Agency Certification
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
CSA LR19980
UL E29179
Manufacturer Part Number: 44432-0802
Molex
