MOTOROLA 74F00PC IC Quad 2-Input NAND Gate

Description

MOTOROLA 74F00PC IC QUAD 2-INPUT NAND GATE 14-Pin Dip
Product: Single-Function Gate
Logic Function: NAND
Logic Family: 74F
Number of Gates: 4 Gate
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
High Level Output Current: – 1 mA
Low Level Output Current: 20 mA
Propagation Delay Time: 5 ns
Supply Voltage – Max: 5.5 V
Supply Voltage – Min: 4.5 V
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package / Case: PDIP-14
Packaging: Tube
Logic Type: 2-Input NAND

74F00 Quad 2-Input NAND Gate
General Description
This device contains four independent gates, each of which performs the logic NAND function.

Ordering Code:
Order Number 74F00SC 74F00SJ 74F00PC Package Number M14A M14D N14A Package Description 14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-120, 0.150 Narrow 14-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide 14-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide

Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.

Manufacturer:Motorola
