Description
MOTOROLA 74LS374N 74LS374PC IC FLIP FLOPS OCTAL 20-PIN DIP
Number of Circuits: 8
Logic Family: LS
Logic Type: Transparent D-Type Latch
Polarity: Non-Inverting
Input Type: TTL
Output Type: TTL
Propagation Delay Time: 28 ns
High Level Output Current: – 2.6 mA
Low Level Output Current: 24 mA
Supply Voltage – Max: 5.25 V
Maximum Operating Temperature: + 70 C
Mounting Style: Through Hole
Package / Case: PDIP-20
Packaging: Tube
Minimum Operating Temperature: 0 C
Number of Input Lines: 4
Number of Output Lines: 2
ON Semiconductor was formally a Division of Motorola called SCG (Semiconductor Components Group). spun off from Motorola in August 1999
These 8-bit registers feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. The high-impedance 3-state and increased high-logic-level drive provide these registers with the capability of being connected directly to and driving the bus lines in a bus-organized system without need for interface or pullup components. These devices are particularly attractive for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.
Manufacturer Part Number: 74LS374PC
Motorola
