Description
MC33362DW High Voltage Switching Regulator 13-Pin SOIC CONTROLLER IC, Input Voltage AC Min:-, Input Voltage AC Max:-, AC / DC Converter Case Style:SOIC, No. of Pins:16, Power Rating:-, Topology:-, Operating Temperature Min:-25°C, Operating Temperature Max:150°C
Output Isolation Isolated
Internal Switch(s) Yes
Voltage – Breakdown 500V
Topology Flyback, Forward
Voltage – Start Up 14.5V
Voltage – Supply (Vcc/Vdd) 9.5 V ~ 40 V
Duty Cycle 50%
Frequency – Switching 67.5kHz ~ 285kHz
Power (Watts) –
Fault Protection Current Limiting, Over Temperature, Over Voltage
Control Features Frequency Control
Operating Temperature -25°C ~ 150°C (TJ)
Package / Case 16-SOIC (0.295″, 7.50mm Width) 13 Leads
Supplier Device Package 16-SOIC
Mounting Type Surface Mount
Manufacturer Part Number: MC33362DW
Manufacturer: Motorola
