EEE-FK1C470UR Panasonic

Panasonic EEE-FK1C470UR Aluminum Electrolytic Capacitor 47uF 16V 20% SMD Radial

EEE-FK1C470UR Panasonic Aluminum Electrolytic Capacitors – SMD 47uF 16V Radial RoHS

ENQUIRY!
SKU: EEE-FK1C470UR Categories: , Tags: , Brand:

Description

Panasonic EEE-FK1C470UR SMD Aluminium Electrolytic Capacitor, AEC-Q200 FK Series, 47 µF, 16 V, Radial Can – SMD, 5 mm

The Panasonic FK series capacitors are automotive grade type V, surface mount polarized aluminium electrolytic capacitors. The capacitance value ranges from 3.3µF to 6800µF. These capacitors are perfect solution for applications, which require ultra low ESR, very high ripple current and very long life in small mounting form.
  • Automotive grade AEC-Q200 compliant
  • High reliability
  • Rated voltage range of 6.3VDC to 100VDC
  • Tolerance of ±20%
  • Endurance of 2000h to 5000h at 105°C
  • Operating temperature range -55°C to 105°C

Applications

Automotive; Industrial; Power Management; Consumer Electronics; Portable Devices

Specifications

Manufacturer: Panasonic
Product Category: Aluminum Electrolytic Capacitors – SMD
RoHS: RoHS Compliant
Brand: Panasonic
Capacitance: 47 uF
Voltage Rating DC: 16 VDC
Tolerance: 20 %
ESR: 700 mOhms
Ripple Current: 160 mA
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 105 C
Diameter: 5 mm
Length: 5.8 mm
Series: FK
Life: 2000 Hour
Height: 5.8 mm
Packaging: Reel
Product: High Temp Electrolytic Capacitors
Factory Pack Quantity: 1000
Termination Style: SMD/SMT
Type: Aluminum Electrolytic Capacitors/Medium-size
Manufacturer Part Number: EEE-FK1C470UR
Manufacturer: Panasonic
