Description
Panjit BAT54CW Diode Schottky 30V 0.2A 3-Pin SOT-323 T/R
Specifications
Product Category: Schottky Diodes & Rectifiers
Product: Schottky Diodes
Mounting Style: SMD/SMT
Package / Case: SOT-323-3
Configuration: Dual Anode Common Cathode
Technology: Si
If – Forward Current: 200 mA
Vrrm – Repetitive Reverse Voltage: 30 V
Vf – Forward Voltage: 1 V
Ifsm – Forward Surge Current: 600 mA
Ir – Reverse Current: 2 uA
Minimum Operating Temperature: – 65 C
Maximum Operating Temperature: + 125 C
Series: BAT54CW
Packaging: Reel
Packaging: Cut Tape
Product Type: Schottky Diodes & Rectifiers
Subcategory: Diodes & Rectifiers
Termination Style: SMD/SMT
Type: Surface Mount Schottky Barrier Diode Array
FEATURES
• Low turn-on voltage
• Fast switching
• PN Junction Guard Ring for Transient and ESD Protection.
• Lead free in comply with EU RoHS 2011/65/EU directives.
• Green molding compound as per IEC61249 Std. . (Halogen Free)
Manufacturer:Panjit
Datasheet:BAT54CW.pdf
