Description
Panjit BAV70 General Purpose, Power Diode Small Signal Switching 70V 0.2A 3-Pin SOT-23 T/R , Surface Mount Switching Diodes
Specifications
Product Category: Diodes – General Purpose, Power, Switching
Mounting Style: SMD/SMT
Package / Case: SOT-23
Peak Reverse Voltage: 70 V
Max Surge Current: 2 A
If – Forward Current: 0.2 A
Configuration: Dual
Vf – Forward Voltage: 1.25 V
Ir – Reverse Current: 5 uA
Minimum Operating Temperature: – 55 C
Maximum Operating Temperature: + 150 C
Series: BAV70
Packaging: Reel
Packaging: Cut Tape
Product Type: Diodes – General Purpose, Power, Switching
Subcategory: Diodes & Rectifiers
Type: Small Signal Switching Diode
Vr – Reverse Voltage: 70 V
FEATURES
• Fast switching speed.
• Surface mount package Ideally Suited for Automatic insertion
• High Conductance
• Lead free in comply with EU RoHS 2011/65/EU directives.
• Green molding compound as per IEC61249 Std. . (Halogen Free)
