Description
Panjit LL4148 Fast Switching Surface Mount Diodes, Small Signal Diode, Single, 100 V, 150 mA Mini-MELF
Package 2Mini-MELF
Type Small Signal Switch ing Diode
Configuration Single
Peak Reverse Repetitive Voltage 100 V
Peak Average Forward Current 0.15 A
Peak Reverse Recovery Time 4 ns
Peak Reverse Current 5@75V uA
Peak Forward Voltage 1@10mA V
Peak Non-Repetitive Surge Current 0.5 A
Operating Temperature -65 to 175 °C
Mounting Surface Mount
Category Rectifier
Manufacturer Panjit
LL4148 Series 1 V 200 mA 100 V Max Reverse Voltage Small Signal Diode – LL-34
FEATURES
• Fast switching Speed.
• Surface Mount Package Ideally Suited For Automatic Insertion.
• Silicon Epitaxal Planar Construction.
• Lead free in compliance with EU RoHS 2011/65/EU directive
Manufacturer:Panjit
Datasheet:LL4148.pdf
