Description
PBIH-11024M Powerbox Powerbox DC / DC Converter Input : 85-140V DC Output : 24V DC, 5A, 100W
INPUT
Input voltage 12Vdc (9.2-16)
24Vdc (19-32)
48Vdc (38-63)
110Vdc (85-140)
Inrush current 20A max. for 110Vdc only
OUTPUT
Output voltage See Selection Table
Voltage adjustment 10%, 5% for PBIH-F
Output current See Selection Table
Ripple & noise Vout x 1% + 50-100mVp-p
Line regulation 0.8% over input range
Load regulation 0.9%, 0%-100% load
Drift Vout x 0.5% + 15mV /8hrs after 1hr warm-up
Rise Time
200ms max. – PBIH-F, M, R
100ms max. – PBIH-G, J (at 25C)
Holdup time 10ms (only 110V input)
Efficiency 70%-89%
Manufacturer:Electronic Components
Datasheet:Others/PBIH_20170602.pdf
