Description
Canal Components PS17-5AB Pushbutton Switch 1A 125-250VAC SPST Panel Mounting, Push-On, Black RoHS
Panel mounting, Off-momentary On, or On-Momentary Off
Rating : 1A 125VAC, 0.5A 250VAC
Contact resistance : 50m ohm
Insulation resistance : DC500V 100M ohm (min.)
Dielectric voltage-withstand : 1,000 VAC for 1 minute
Operation force : 200 +-100 gram
Life cycle : 10,000 cycles
Temperature range : 0 to + 65 degrees in Celsius
Washer : Brass
Nut : Steel
Cap : ABS, optional knob and color
Shaft : Brass
Body : Phenolic
Terminal : Brass
Manufacturer:Canal
Datasheet:IBSPS17-5AB.pdf
