Description
RS-01A-B(A1) SWITCH 1 POSITION 50mA, 24VDC BLUE RoHS
SMD mounting height 2.5mm low profile design
Complies with EIAJ SOP standard outline dimensions
Seal tape type
Excellent contact stability with twin Au plated contacts
Technical specification
Contact Rating 6Vdc 100mA; 24Vdc 25mA
(Switching)
Contact Resistance 50m? max.
Insulation Resistance 1000M? (100Vdc) minimum
Load Life 2000 cycles
Operating Temperature -40°C to +85°C
Withstand Voltage 500Vac 50Hz 60s
Terminal Shape J-Hook
Manufacturer Part Number: RS-01A-B(A1)
Manufacturer: Canal
