Description
S18B-PHDSS-B(LF)(SN) JST Rectangular Connector Header Shrouded 7 Position 1.5mm Solder ST Thru-Hole Box RoHS
Specifications
Type Shrouded Header (4 Sides)
Gender HDR
Number of Contacts 18
Number of Rows 2
Termination Method Solder
Terminal Pitch (mm)2
Body Orientation Right Angle
Polarization Type Dual Slot
Row Spacing (mm) 2
Maximum Current Rating (A)3
Maximum Voltage Rating 250VAC|250VDC
Insulation Resistance (MOhm) 1000
Maximum Contact Resistance (mOhm)20
Minimum Operating Temperature (C)-25
Maximum Operating Temperature (C)85
Packaging Box
Product Length (mm)19.9
Product Depth (mm)9.5
Product Height (mm)5
Mounting Through Hole
Manufacturer: JST
MFG Part #: S18B-PHDSS-B(LF)(SN)
