Description
SL202510G SL 2 025 10 G Fischer elektronik PCB connector, Male header 10 Posistions, Dual RoHS
Features
2.54 mm
no. of contacts
2 / 4 / 6 / 8 / 10 / 12 / 14 / 16 / 18 / 20 / 22 / 24 / … / 72
contact material
CuSn alloy
surface of contact
selective gold-plated
gold-plated
tin-plated
surface contact / contact sleeve
Ni+>=0.2um Au
Ni+4…6um Sn
version standard
volume resistance <=5 mOhm
nominal current 3 A
nominal voltage 250 V AC
test voltage 2000 V
insulating body material PA 4.6. GF
temperature range -40C… +163C
(260C/10 s)
class of inflammability UL 94 V-0
specific insulation resistance >10.07.0 Ohmm
reflow solderable yes
Manufacturer Part Number: SL-2-025-10-G
Manufacturer: Electronic Components
