Description
SMP-02V-BC JST Connector Housing For SM Series Number of pins: 2 Nominal current 3A 2 Position, 2.50mm, Panel Mount, Snap In, Locking Ramp, Black RoHS
Vibration-proof, lockable connector for wire to wire. Contacts countersuck, high pressure contact. The catch bars on the housing and pin header make an audible click when plugged. A circular trough at the pin header ensures reverse voltage protection.
Highlights & Details
Content: 1 pc(s)
No. of rows: 1
Total number of pins: 2
Technical data
Connector type: Socket strip, straight:
Connectors: wire-to-wire:
Series: SM:
CS: 2.50mm:
Pins per row: 2:
Total number of pins: 2:
Nominal current: 3A:
Nominal current – rounded value: 3A:
Content: 1pc(s):
Dim: (L x W x H) 18.2 x 8 x 7.5 mm:
Colour: Ecru:
Height: 7.5mm:
Length: 18.2mm:
Width: 8mm:
Industrial packaging: No:
Manufacturer part #: SMP-02V-BC:
Type: SMP-02V-BC:
Material (details): PA 6 UL94V-0:
Type: Housing for socket contacts:
Insulation material: Polyamide:
Nominal voltage (details): 250V AC:
Nominal current (details): 3A:
No. of rows: 1:
Cross section: 0.08 – 0.33mm:
Number of pins: 2:
Connection: Crimp:
Case material: Polyamide:
RoHS-compliant: Yes:
Product type: Socket enclosure – cable
Manufacturer:Electronic Components
Datasheet:JST/eSM.pdf
