Description
STMicroelectronics / SGS 74SC244P Octal buffer/line driver, 3-state
Logic IC Type BUS DRIVER
Sub Category Bus Driver/Transceivers
Control Type ENABLE LOW
JESD-30 Code R-PDIP-T20
JESD-609 Code e0
Load Capacitance (CL) 50 pF
Max I(ol) 0.0120 Amp
Number of Bits 4
Number of Functions 2
Number of Terminals 20
Operating Temperature-Min -40 Cel
Operating Temperature-Max 85 Cel
Output Characteristics 3-STATE
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP20,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supplies (V) 5
Prop. Delay@Nom-Sup 35 ns
Qualification Status Not Qualified
Supply Voltage-Nom (Vsup) 5
Surface Mount NO
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Manufacturer:STMicroelectronics
Datasheet:SUPRS02716-1.pdf
