Description
SGS – STMicroelectronics SMP100-230 IC TVS BIDIRECT 25V BULK
Product Category: Sidacs
RoHS: No
Breakover Voltage VBO: 300 V
Breakover Current IBO Max: 50 A
Non Repetitive On-State Current: 50 A
Rated Repetitive Off-State Voltage VDRM: 220 V
Off-State Leakage Current @ VDRM IDRM: 0.005 mA
Holding Current Ih Max: 800 mA
On-State Voltage: 3.5 V
Maximum Operating Temperature: + 150 C
Mounting Style: SMD/SMT
Package / Case: SMB
SMP100LC-230 Parametrics
Parameters Values
Case/Package: SMD
Number of Pins: 2
Capacitance: 30.0 pF
Voltage Rating (DC): 230 V
Holding Current: 150 mA
Size-Length: 4.60 mm
Size-Width: 3.95 mm
Size-Height: 2.45 mm
Mounting Style: Surface Mount
Packaging: Cut Tape (CT)
REACH SVHC Compliance: No SVHC
Lead-Free Status: Lead Free
RoHS: Compliant
Product Lifecycle Status: Active
SMP100LC-230 Product Overview
The Trisil SMP100LC series low capacitance TVS Diode for telecom equipment protection. It is designed for the protection of high data rate communication equipment. The low capacitance of the devices avoids any distortion of the signal and is compatible with digital transmission line cards (xDSL, ISDN). The device is tested and confirmed compatible with Cooper Bussmann Telecom Circuit Protector TCP 1.25A. It is suitable for any sensitive equipment requiring protection against lightning strikes and AC power faults. It is dedicated to central office protection as they comply with the most stressful standards.
.Bidirectional crowbar protection.Voltage range from 8 V to 400 V.Low capacitance from 20pF to 45pF @ 2V.2µA Maximum low leakage current IR.150mA Minimum holding current IH.100A (10/1000µs) Repetitive peak pulse current IPP.-40 to 150°C Operating junction temperature range
Manufacturer:STMicroelectronics
Datasheet:pdf_ST-Microelectronics_613038.pdf
