Description
Low saturation type regulator, Renesas Electronics (NEC)
LDO (Low Dropout) Linear Voltage Regulator, Renesas Electronics
It is a low dropout (LDO) type linear voltage regulator. A wide range of linear regulator products are available. The LDO regulator can operate with small input / output differential pressure. It can provide fast transient response, wide input voltage range, low quiescent current, low noise high PSRR.
specification
Output voltage 15 V
Output type Fixed
Package type MP-45G
Maximum output current 500 mA
Mounting type Through hole
Minimum input voltage 16 V
Maximum input voltage 27 V
Number of pins 3
Number of outputs 1
accuracy 2%
Minimum operating temperature -20 C
Maximum operating temperature + 85 C
Line regulation 150 mV
length 10.4 mm
Size 10.4 x 4.5 x 8.5 mm
width 4.5 mm
Load regulation 75 mV
height 8.5 mm
Manufacturer:Renesas
Datasheet:UPC24M15AHF.pdf
