Description
The Quatro is a highly integrated, fully programmable processor for laser printers, multifunction peripherals, and high speed scanners. Based on Zoran’s Quatro architecture, the 4230 combines an embedded ARM11TM RISC CPU core and dual Quatro SIMD DSP cores for high quality copy image processing
and page description language (PDL) acceleration, providing original equipment manufacturers (OEMs) with a compelling combination of high-performance and programmability.The 4230 is ideal for applications such as monochrome and color laser MFPs and high-speed document scanners.
Fast time-to-market Programmable platform for deploying innovative features and associated image processing pipelines Cost-effective solution High level of integration including USB, Ethernet, and PCI interfaces High performance Specialized imaging DSP cores paired with high-performance ARM11 CPU PostScript/PCL printing at 16+ ppm color Raster/GDI printing at 30 ppm (4-bit CMYK) 12 full-coverage color copies per minute at 600 dpi 55 full-coverage monochrome copies per minute at 600 dpi
400 MHz ARM11 CPU core with MMU and FPU Dual 300 MHz quad-processor DSP cores 2400 MMACs DSP bandwidth USB 2.0 hi-speed device interface USB 2.0 hi-speed host interface USB 2.0 full-speed host interface 200 MHz 32-bit DDR2 SDRAM interface 32-bit 66 MHz PCI interface Ethernet MAC Scanner interface Programmable printer interface for multipass and tandem engines, inkjet engines, and dye-sub engines Memory card interface: CompactFlash and SmartMedia Complete reference design Extensive image processing library
Manufacturer:Electronic Components
Datasheet:QUATRO4100.pdf
