Description
Features
PC/104 form factor
PCI/104-Express stackable bus structure
PCIe universal expansion bus (Type 1 or Type 2)
PCI pass-through expansion bus
PCIe x1 interface
High Power Capacity
88W maximum output power
Operational from -40C to +85C
All supplies are Synchronized to reduce noise and system stress
Efficiency as high as 90%
Wide Input Voltage Range
8-32 Vdc Unregulated DC input (36V absolute maximum)
Low input capacitance
Low input current ripple
Reverse Polarity Protection to 40 Volts
Input Voltage Transient Protection
Outputs
+5 Vdc Standby at 1.0 A
+5 Vdc at 10.0 A
+3.3 Vdc at 10.0 A
+12 Vdc at 2.0 A
-12 Vdc at 500 mA
Status LEDs
Placed conveniently next to the PCI-Express Bus for easy viewing
Remote ON/OFF operation available
Physical Attributes
Dimensions
Length (L): 3.775 inches (95.89 mm)
Width (W): 3.550 inches (90.17 mm)
Stand-off Height: 0.600 inches (15.24 mm)
Weight: Approximately 0.16 lbs. (0.07 Kg)
Standard Operating Temperature, 90% humidity non-condensing: -40 to +85C
Storage Temperature: -55 to +125C
MTBF: 2,592,399 hours
Manufacturer:Electronic Components
Datasheet:ATX104EX_BDM610020070H.pdf
