Description
CCR05CG101GR Cap Ceramic Radial Molded 5.08mm LS 100pF CG 200V 2 % (6.22mm x 5.08mm x 2.5 4mm) Manufacturer: AVX
SPECIFICATIONS
| Mfr Package Description | RADIAL LEADED |
| REACH Compliant | Yes |
| Status | Active |
| Capacitor Type | CERAMIC CAPACITOR |
| Capacitance | 1.0E-4 µF |
| Dielectric Material | CERAMIC |
| Manufacturer Series | CCR |
| Mounting Feature | THROUGH HOLE MOUNT |
| Multilayer | No |
| Negative Tolerance | 2.0 % |
Technical Attributes
Lead Diameter0.64 mm
Tolerance 2 %
Package/Case 4.83 X 2.29 X 4.83
Lead Finish Tin/Lead
Failure Rate R
Wire Form Outside Bend
Voltage(DC) 200 V
Capacitance Value 100 pF
Mounting Through Hole
Operating Temperature -55 to 125 °C
Dielectric C0G
Lead Pitch For Radial 5.08 mm
Termination Style Radial
Case Style Molded
Max Processing Temp 260
Product Length 4.83 mm
Manufacturer Part Number: CCR05CG101GR
AVX
